7 Maintenance

The RO1 robot and controller are designed for long life with minimal maintenance. If the robot is installed according to the intended use instructions the robot and controller will provide years of service.

7.1 User-Serviceable Parts

Part Description Part # Replacement Interval
Control Box Fan Filter 120mm Sq Nylon Mesh 8 Micron Filter SB-0596-A 6 months, application dependent

7.2 Replacement Procedures

7.2.1 Controller Fan

  1. Stop the robot.

  2. Apply the robot brakes through the Move Robot view in the user interface.

  3. Unplug the controller.

  4. Wait 30 seconds for power to dissipate.

  5. Tape up the area as shown below to avoid damaging surface:

Tape Area

  1. Measure from corner of fan shroud and mark tape at 1.5” and 4.5”:

  1. Insert a flat head screwdriver just past the lip of the shroud and pry one side out. You will hear a snap noise:
Pry Shroud

  1. Repeat for the other side:

  1. Pull shroud downward and remove shroud as shown:
Pry Shroud

  1. Remove and replace filter:
Remove Shroud

  1. Engage bottom of shroud with bottom of assembly:
Replace Shroud

  1. Press in top of shroud with hand.

  2. Remove tape.

7.3 Limited Product Warranty

Standard Bots Company (the “Company”) warrants to the original lessor of the Standard Bots Robot (the “Original Purchaser” and the “Product”, respectively ) from the Company, that the Product shall be free from defects in materials and workmanship under normal use and in conformance with the Company’s instructions, for so long as such Original Purchaser continues to lease the Product from the Company (the “Warranty Period”).

If a defect arises during the Warranty Period, the Company will, at its option, (i) repair the Product at no charge, using new or refurbished replacement parts, (ii) exchange the Product with a refurbished or new product with equivalent functionality or (iii) provide the Original Purchaser with a replacement part accompanied by instructions on installation, and any requirements for the disposal of the replaced part. The Company shall not be responsible for any labor costs you incur relating to DIY parts service.

This warranty excludes (i) normal depletion of consumable parts such as batteries and (ii) defects caused by the user’s fault.

This warranty is subject to your following the RMA process as may be in place at the Company from time to time. In order to obtain warranty service, please contact customer service at [email protected]. It is your responsibility to backup any data, software or other materials you may have stored on the Product, as such data, software or other materials may be lost or reformatted during warranty service and the Company will not be responsible for such loss. In addition, it is your sole responsibility to delete all sensitive and personal information stored in, or in accessible form in, the Product prior to shipping the Product to us, and to disable or remove all security passwords.

Without derogation, this warranty does not apply in any of the following cases:

- Products not leased from the Company

- Damage caused by accident, abuse or misuse

- Products that have been dismantled, tampered with, modified or repaired by anyone other than the Company or a service provider authorized by the Company.

7.4 Return Merchandise Authorization

Should you believe you need to return a Standard Bots product please contact us through one of the below contact methods. Unauthorized returns will not be accepted.

Standard Bots Support: Phone: 888-976-1287 Email: [email protected]
